PDU metered

Metered PDU with local information of power usage

Show fewer

The metered Power Distribution Unit with local input current meter allow network engineers to utilize the True RMS power monitor of the PDU to precisely measure the current (in A) that the IT devices are drawing from the power circuit. When new servers and devices are added to the server rack in the server room or datacenter, the impact on the cumulative power consumption can be observed immediately. Thus allowing the engineer to load each circuit to its maximum capacity without the danger of overloading causing possible failure of the PDU in the server rack.

Aluminium,1U
Power Meter (kWh + A)
Standard Power cord length 3 meter
Including universal mounting brackets for horizontal (19”) and vertical mounting (0U) of the PDU

	Article	Description	MAX. CURRENT (A)	RATED VOLTAGE / PHASE	OUTLETS	INPUT PLUG	LENGTH HOUSING (mm)	Order
	PLA416-6PM	PDU 1x16A, 6xSchuko, Power Meter, Schuko Power Cord	16	230V / 1~	6x Schuko	Schuko	426
MAX. CURRENT (A) 16 RATED VOLTAGE / PHASE 230V / 1~ OUTLETS 6x Schuko INPUT PLUG Schuko LENGTH HOUSING (mm) 426 Colour Black With mounting material Yes Temperature measurement No Ampere meter No With fuse No With LED indication No With display Yes SNMP No Control function No With meter Yes Switchable No Mains filter No Supply voltage 230 V Height 44.4 mm Number of height units 1 Number of other socket outlets 0 Number of socket outlets Swiss standard type 25 0 Number of socket outlets Swiss standard type 23 0 Number of socket outlets Swiss standard type 15 0 Number of socket outlets Swiss standard type 13 0 Number of socket outlets British Standard BS1363 0 Number of C20 socket outlets 0 Number of C19 socket outlets 0 Number of C13 socket outlets 0 Number of socket outlets with earth pin 0 Number of socket outlets with protective contact CEE 7/3 (type F) 6 Number of miniature circuit breakers (MCB) 0 Number of phases 1 Electrical connection Connection cable with plug Mounting direction Horizontal Mounting dimension (standardised) 482.6 mm (19 inch) more info »
	PLA416-9PM	PDU 1x16A, 9xC13, Power Meter, Schuko Power Cord	16	230V / 1~	9x C13	Schuko	426
MAX. CURRENT (A) 16 RATED VOLTAGE / PHASE 230V / 1~ OUTLETS 9x C13 INPUT PLUG Schuko LENGTH HOUSING (mm) 426 Colour Black With mounting material Yes Temperature measurement No Ampere meter No With fuse No With LED indication No With display Yes SNMP No Control function No With meter Yes Switchable No Mains filter No Supply voltage 230 V Height 44.4 mm Number of height units 1 Number of other socket outlets 0 Number of socket outlets Swiss standard type 25 0 Number of socket outlets Swiss standard type 23 0 Number of socket outlets Swiss standard type 15 0 Number of socket outlets Swiss standard type 13 0 Number of socket outlets British Standard BS1363 0 Number of C20 socket outlets 0 Number of C19 socket outlets 0 Number of C13 socket outlets 9 Number of socket outlets with earth pin 0 Number of socket outlets with protective contact CEE 7/3 (type F) 0 Number of miniature circuit breakers (MCB) 0 Number of phases 1 Electrical connection Connection cable with plug Mounting direction Horizontal Mounting dimension (standardised) 482.6 mm (19 inch) more info »
